Performance data
Review flow output, operating pressure, and friction-loss behavior in a native chart view without relying on rasterized images.
Switch between diameter and flow-rate combinations to compare curves.
Active configuration
Diameter
16MM
Flow rate
4 LPH
Output
LPH
Performance data
Nominal flow output across the published operating-pressure range.
Diameter
16MM
Flow rate
4 LPH
Output
LPH
| Pressure (bar) | 0.34 | 0.69 | 1.03 | 1.38 | 1.72 | 2.07 | 2.41 | 2.76 | 3.1 | 3.45 |
|---|---|---|---|---|---|---|---|---|---|---|
| Output (LPH) | 2.27 | 3.33 | 4.01 | 4.73 | 5.30 | 5.91 | 6.28 | 6.74 | 7.15 | 7.53 |
Performance data
Pressure loss by lateral length and emitter spacing.
Diameter
16MM
Flow rate
4 LPH
Emitter spacing
cm
Emitter spacing
